Humminbird Helix 7 CHIRP Mega DI GPS G4-Floor Model

sorry, Humminbird Helix 7 CHIRP Mega DI GPS G4-Floor Model is currently out of stock

Humminbird Helix 7 CHIRP Mega DI GPS G4-Floor Model

Sorry, this item is out of stock

About This Item

FLOOR MODEL:

  • All floor models are sold as is, final sale
  • Website images do not reflect the actual condition of the equipment

SONAR:

  • Humminbird® Basemap provides a clear view of underwater terrain allowing you to identify buoys, day markers, hazards, contours, depth markings and more
  • CHIRP digital sonar allows you to view details that other forms of sonar won't show that are engineered to help you see individual fish, clearly identify bait, and structure, and reach greater depths and range
  • MEGA Down Imaging provides coverage down to 125 feet below the boat with 3x more detail
  • Dual Spectrum CHIRP 2D sonar is powered by Low-Q CHIRP transducer to offer two different search options: Narrow mode for focusing on small details and Wide Mode for all-out coverage

NAVIGATION:

  • AutoChart LIVE create real-time maps of your fishing spots, map depth contours, bottom hardness, and vegetation as you drive your boat, with eight hours of built-in recording time
  • Humminbird® and internal GPS includes charts of over 10,000 lakes with coastal coverage for the continental U.S.
  • Precision GPS gives more accurate waypoints and boat position due to accurate position fix for a better fishing experience
  • AIS tracks other vessels for easy navigation of high-traffic areas and low-visibility waters
  • Humminbird® Autopilot® maintains turn patterns and desired route regardless of weather conditions and speed
  • Smartstrike&trad; cards combine high definition LakeMaster® lake map data for extensive algorithms for easy location of fish and patterns during each season
    • CONNECTIVITY:

  • User-friendly menu system with pre-loaded views and softkey controls for easy and reliable operation in any conditions
  • ADDINTIONAL DETAILS:

  • Includes transom-mount transducer, control head, gimbal mounting bracket, power cable, and mounting hardware
  • Single slot SD slot for easy transfers
  • High-definition display for clear imagery
      • Web ID: 22HMBUHLX7CHRPMDGFEL
      Model411610-1
      Display Size - Diagonal7 in.
      Display Pixel Matrix1024H x 600V
      Sonar StandardDual Spectrum CHIRP, MEGA Down Imaging
      Sonar-Coverage20°, 42°, 60° & (2) 86° @ -10dB
      Sonar-Optional53 kHz, 50/Low Airmar CHIRP
      CHIRP - Frequencies Supported83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz)
      Sonar-Frequencies Supported50/83/200/455/800 kHz & 1.2 MHz
      Depth-Sonar1,200 ft (standard transducer), 3,500 ft (optional 50 kHz)
      CHIRP - Imaging-Frequencies Supported455 kHz (440-500 kHz), MEGA DI (1075-1150 kHz)
      Depth-Down Imaging400 ft (455 kHz), 75 ft (MEGA)
      InterfaceKeypad Control
      FeaturesBuilt In GPS, Built In Mapping, Dual Spectrum CHIRP, Down Imaging, MEGA Imaging
      Memory Card SlotSingle Micro SD
      Compatible WithAIS, AutoPilot, Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI
      Power Draw800 mA
      Power Input10.8-20 VDC
      Power Output Peak-to-Peak4000 Watts
      Power Output RMS500 Watts
      Screen Snap ShotIncluded
      Sonar RecordingIncluded
      Mount-StandardGimbal
      Mount-Standard Size10.54" W x 5.8" H x 3.68" D
      Mount-Optional Size10.54" W x 5.44" H x 1.13" D
      Transducer Mount LocationTransom
      GPS ChartplottingIncluded
      GPS TrackplottingYes
      Transducer IncludedNo
