Wheel Size
Brake Type
Suspension
| Frame Sizes: | XS, S |
|---|---|
| Frame: | ALUXX-Grade Aluminum, disc |
| Fork: | SR Suntour XCE XS: 80mm travel (27.5) S: 100mm travel (27.5) / 100mm travel |
| Shifters: | microSHIFT SL-M718, 1x8 |
|---|---|
| Rear Derailleur: | microSHIFT RD-M619 |
| Crankset: | ProWheel A10XPP, 30t (27.5) XS: 165mm (27.5) S: 165mm (27.5) |
| Chain: | KMC 8.3 |
| Cassette: | microSHIFT CS-H083, 12-46 |
| Brakeset: | TKB-172, mechanical [F]160mm, [R]160mm rotors |
|---|---|
| Brake Levers: | RS360A, mechanical |
| Wheel Size: | 27.5" |
|---|---|
| Rims: | Giant GX03V 27.5, alloy, double wall, 21mm inner width |
| Tires: | Kenda Booster 27.5" |
| Hubs: | Alloy, ball bearing |
| Handlebar: | Giant Connect Trail, 31.8mm XS: 670mm (27.5) S: 670mm (27.5) |
|---|---|
| Stem: | Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) |
| Grips: | Giant Sole-O |
| Seat Post: | Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) |
| Saddle: | Liv Sport |
| Frame Size: | XS | S |
|---|---|---|
| Seat Tube Length (in.): | 12.8 | 14.4 |
| Seat Tube Angle: | 74.0° | 74.0° |
| Top Tube Length (in.): | 21.3 | 22.5 |
| Head Tube Length (in.): | 3.7 | 3.9 |
| Head Tube Angle: | 68.0° | 68.0° |
| Fork Rake (in.): | 1.6 | 1.7 |
| Trail (in.): | 4 | 3.9 |
| Wheelbase (in.): | 42.2 | 43.5 |
| Chain Stay Length (in.): | 17.3 | 17.3 |
| Bottom Bracket Drop (in.): | 1.6 | 1.8 |
| Stack (in.): | 21.8 | 22.8 |
| Reach (in.): | 15.1 | 15.9 |
| Stand Over Height (in.): | 26.1 | 27 |
| Handlebar Width (in.): | 28.7 | 29.5 |
| Stem Length (in.): | 1.6 | 1.6 |
| Crank Length (in.): | 6.5 | 6.5 |
