Lowrance Elite FS 9" Fish Finder

|
About This Item

FEATURES:

  • ActiveTarget™ Live Sonar ready
  • Active Imaging 3-in-1 ready
  • FishReveal™ technology
  • Preloaded C-MAP® Contour+ inland and coastal charts with high resolution, bathymetric 1-foot contours on 15,000+ U.S. Lakes and 9,400+ lakes in Canada
  • Mapping options including C-MAP, Navionics® and more
  • C-MAP® Easy Routing, Navionics® Autorouting capability
  • C-MAP Genesis Live onscreen mapping
  • High-resolution multi-touch touchscreen
  • Integrated wireless, NMEA 2000® and Ethernet connectivity
  • Full touchscreen control of Power Pole® anchors and Ghost® Trolling Motor
  • Brand : Lowrance
  • Country of Origin : Imported
  • Web ID: 24LOWULTFS9SCNCHXFEL
  • SKU: 21751756
Backlight ColorPure White LED
Display Resolution800x480
Viewing Angles50° top 60°bottom 70° left/right
BluetoothIntegrated Bluetooth 4.0 with support for Bluetooth Classic
Connectivity Wi FiInternal 802.11b/g/n
SD Card Storage1 micro SD card up to 32GB
VideoNone
Charts supportedC-MAP (MAX N, MAX N+) C-MAP Genesis C-MAP Precision Contour HD (AMER ONLY) Navionics (Gold, NAV+ Platinum+) Insight (Pro and HD) Lowrance Regional Mapping Partners
Supply Voltage12v DC (10.8-17VDC)
WaterproofratingIPX7 with card door closed
GPS10 Hz Internal high-sensitivity WAAS + EGNOS + MSAS
Sonar CompatibilityIntegrated: CHIRP Broadband Active Imaging DownScan Active Imaging SideScan Compatible with: SonarHub StructureScan StructurreScan 3D LiveSight Active Target
Waypoints, Routes, Tracks3000 Waypoints 100 Routes 100 Trails with up to 10,000 points per trail
Mounting TypeGimbal Bracket or Dash Flush Mount
Weight2.7 lbs (1.2 kg)
InterfaceMulti-Touch Touchscreen Zoom +/- MOB = (+/- combined) Pages Waypoint Light/Power

REVIEWS

3.9
81%
Recommended

24 Reviews

Images

No Transducer

This advertisement would lead one to believe this item marked down from $1099 to $849 included the transducer. BUYER BEWARE, IT DOES NOT!

Shutting Down And Re-booting All On Its Own.

Keeps shutting down then re-booting all by itself. Shuts down when pushing the page button. Power button is mixed up with dimming button (real pain in the). After shutting down using normal power button unit re-boots all by itself. Have checked power added dedicated power and ground. Have done soft reset to factory, have done full factory upgrade all to no avail. Now find out I am way past warranty. Other than that unit is nice when on and working.

Excellent Produt

I bought this unit earlier this and I am very pleased with even though I'm still learning.

Van75

I have owned the FS-9 since November of 2021 and love it. I feel safe with it on my boat, and I'm not afraid to visit unfamiliar areas using my FS 9...

Fantastic

I bought this a while ago and really think for9 inch they are great
