Hit the trails with the Standpoint, a Schwinn Signature® mountain bike. The Standpoint features an aluminum mountain frame with Schwinn suspension fork for controlled riding on the trail. 21 speed shifters provide quick gear changes, while front and rear v-brakes deliver crisp stops. Plus, 27.5 x 2.2-inch all-terrain tires give you go-anywhere traction.
| Wheel Size: | 27.5 inches |
| Frame: | 6061 aluminum, 27.5" mountain tuned geometry, internal cable routing, 10 mm x 135 mm dropout, replaceable hanger, 1 1/8 in headtube |
| Fork: | Schwinn, 27.5", steel steerer, 9 mm x 100 mm QR, 60 mm travel |
| Headset: | Threadless, EC34 |
| Crank: | Schwinn aluminum mountain, 42/34/24T |
| Bottom Bracket: | Semi-cartridge, square taper, 68 mm |
| Front Derailleur: | 31.8 mm clamp |
| Rear Derailleur: | 7-speed gearing |
| Cog Set: | 7-speed, 14-28T |
| Shifters: | Twist shifters |
| Speeds | 21 |
| Chain: | 7-speed typ |
| Front Hub: | Steel, 9 mm x 100 mm QR, 36H |
| Rear Hub: | Steel, 135 mm bolt-on, 36H |
| Spokes: | 14G, steel |
| Rims: | Aluminum, 36H |
| Tires: | Schwinn mountain, 27.5 in x 2.2 in, wire bead |
| Brakes: | V-brake, aluminum |
| Brake Levers: | aluminum |
| Pedals: | Schwinn platform, nylon |
| Handlebar: | Steel, 660 mm width, 20 mm rise |
| Grips: | Schwinn mountain Kraton |
| Stem: | Aluminum, threadless, 10° rise |
| Saddle: | Schwinn mountain, steel rails |
| Seat Post: | Steel, 300 mm, 27.2 mm |
